Rigol DHO1202 Manual

Overview of the DHO1000 Series Technical Specifications
Bandwidth
Limit
20 MHz, FULL; selectable for each channel
Max. Analog
Channel
Sample Rate
2-channel model: 2 GSa/s (single channel
[1]
), 1 GSa/s (all
channels
[3]
)
4-channel model: 2 GSa/s (single channel
[1]
), 1 GSa/s (half
channels
[2]
), 500 MSa/s (all channels
[3]
)
Standard
Memory Depth
2-channel model: 50 Mpts (single channel
[1]
), 25 Mpts (all
channels
[3]
)
4-channel model: 50 Mpts (single channel
[1]
), 25 Mpts (half
channels
[2]
), 12.5 Mpts (all channels
[3]
)
Optional
Memory Depth
2-channel model: 100 Mpts (single channel
[1]
), 50 Mpts (all
channels
[3]
)
4-channel model: 100 Mpts (single channel
[1]
), 50 Mpts (half
channels
[2]
), 25 Mpts (all channels
[3]
)
Max. Waveform
Capture Rate
50,000 wfms/s (Vector Mode)
1,500,000 wfms/s (UltraAcquire Mode)
Vertical
Resolution
12 bits
DC Gain
Accuracy
±2% Full Scale
Time Base
Accuracy
±0.5 ppm ± 1 ppm/year
Trigger Source Analog channel (1-4), EXT TRIG, and AC Line
NOTE
[1]: If any one of the channels is enabled, it is called single channel mode.
[2]: For 4-channel models, if two of the channels are enabled, it is called half channels mode.
[3]: For 2-channel models, if two channels are enabled, it is called all channels mode. For 4-
channel models, if any three channels or all four channels are enabled, it is called all channels
mode.
