Specifications
This chapter lists the technical specifications of the DHO1000 series oscilloscope.
DHO1000 series digital oscilloscope achieves 2 GSa/s sample rate, a fast waveform
capture rate of 1,500,000 wfms/s with the UltraAcquire mode, 100 Mpts memory
depth, 12-bit vertical resolution, all combined with excellent noise floor performance
and vertical accuracy to meet your requirements for more accurate measurements,
bringing extraordinary T&M experience for you.
To meet specifications, these conditions must be met:
• The instrument must have been calibrated in an ambient temperature between
18°C and 28°C.
• The instrument must be operating within the environmental limits. (For the
specific environment requirements, refer to
DHO1000 Data Sheet
).
• The instrument must be powered from a source that meets the requirement for
the power supply. (For the power specifications, refer to
DHO1000 Data Sheet
).
• The instrument must have been operating continuously for at least 30 minutes
within the specified operating temperature range.
The following table shows some of the technical specifications of DHO1072,
DHO1074, DHO1102, DHO1104, DHO1202, and DHO1204. For other technical
specifications of DHO1000, please refer to
DHO1000 Data Sheet
.
Table 2.1 Specifications
Overview of the DHO1000 Series Technical Specifications
Model DHO1072 DHO1074 DHO1102 DHO1104 DHO1202 DHO1204
Analog
Bandwidth (-3
dB)
70 MHz 70 MHz 100 MHz 100 MHz 200 MHz 200 MHz
No. of Input
Channels
2+EXT 4+EXT 2+EXT 4+EXT 2+EXT 4+EXT
Input Coupling DC, AC, or GND
Input
Impedance
1 MΩ ± 1%
Sampling
Mode
Real-time sampling
Specifications
DHO1000 Performance Verification
4
