Document Overview

This manual gives you a quick overview of the front and rear panel, user interface as

well as basic operation methods of DHO800 series.

TIP

For the latest version of this manual, download it from RIGOL official website

Publication Number

QGA36101-1110

Software Version

Software upgrade might change or add product features. Please acquire the latest

version of the manual

Format Conventions in this Manual

1. Key

The front panel key is denoted by the menu key icon. For example,

indicates the "Default" key.

2. Menu

The menu it

em is denoted by the format of "Menu Name (Bold) + Character

Shading" in the manual. For example,

Setup indicates the "Setup" sub-menu under

the "Utility

" function menu. You can click or tap

Setup to access the "Setup" menu.

Operation Procedures

The next step of the operation is denoted by ">" in the manual. For example,

> Storage indicates fir

st clicking or tapping

and then clicking or tapping

Storage.

4. Connect

The front/rear panel connector is denoted by "Brackets + Connector Name (Bold)",

for example, [AUX OUT].

Content Conventions in this Manual

DHO800 series digital oscilloscope includes the following models. Four-channel

models and two-channel models share the same operation method. Unless otherwise

specified, this manual takes the four-channel model DHO814 as an example to

illustrate the operation methods of DHO800 series oscilloscope.

Document Overview

Rigol DHO802 Quick Guide
