Parameter Factory Settings

Frequency Range 10 MHz

Vertical Scale 20 dB

Offset 0 dBV

Window Function Hanning

Color Grade OFF

Peak Search OFF

Peak Number 5

Threshold 5.5 dBV

Threshold 1.8 dB

Order Amp Order

A&&B

Operation OFF

Source A CH1

Source B CH1

Waveform Size Medium

Offset 0 div

Sensitivity 300 mdiv

Thre.CH1 0 V

Thre.CH2 0 V

Thre.CH3 0 V

Thre.CH4 0 V

A||B

Operation OFF

Source A CH1

Source B CH1

Waveform Size Medium

Offset 0 div

Sensitivity 300 mdiv

Thre.CH1 0 V

Thre.CH2 0 V

Thre.CH3 0 V

Thre.CH4 0 V

A^B

Operation OFF

Source A CH1

Source B CH1

Waveform Size Medium

Offset 0 div

Sensitivity 300 mdiv

Thre.CH1 0 V

Thre.CH2 0 V
