Parameter Factory Settings

Thre.CH3 0 V

Thre.CH4 0 V

Operation OFF

Source A CH1

Waveform Size Medium

Offset 0 div

Sensitivity 300 mdiv

Thre.CH1 0 V

Thre.CH2 0 V

Thre.CH3 0 V

Thre.CH4 0 V

Intg

Operation OFF

Source CH1

Scale 500 mV*s

Offset 0 V*s

Offset 0 V

Diff

Operation OFF

Source CH1

Scale 500 mV/s

Offset 0 V/s

Smooth 5

Sqrt

Operation OFF

Source CH1

Scale 500 mU

Offset 0 U

Operation OFF

Source CH1

Scale 500 mU

Offset 0 U

Operation OFF

Source CH1

Scale 500 mU

Offset 0 U

Exp

Operation OFF
