Rigol DHO924S

To Next Page

To Previous Page

Data Source

Clock Source

T2 is the hold time

T1 is the setup time

Edge

The data type is H

Figure 8.20 Setup/Hold Trigger

Trigger Type

Click or tap the drop-down button of Type to select "Setup/Hold".

Figure 8.21 Setup/Hold Trigger Setting Menu

After a trigger type is selected, the current trigger setting information (including the

trigger type, source, and level) is displayed in the trigger information label at the top

of the screen, as shown in the figure below. The information will change based on the

trigger settings.

Triggering the Oscilloscope
