Frequency and Period Characteristics
Accuracy Specifications (% of reading)
[1]
Function
Range
Frequency
Range
1 Year
23℃±5℃
Temperature
Coefficient
0 ℃ to 18 ℃
28 ℃ to 55 ℃
Frequency
Period
200mV
to 750V
[2]
3Hz-5Hz
0.10
0.005
5Hz-10Hz
0.07
0.005
10Hz-40Hz
0.02
0.005
40Hz-300kHz
0.02
0.005
20mA to10A
[3]
3Hz-5Hz
0.10
0.005
5Hz-10Hz
0.07
0.005
10Hz-10kHz
0.02
0.005
Notes：
[1] Specifications are for 60 minute warm–up.
[2] For AC input voltages 10% to 120% of range except where noted. 750V range limited to
750VRMS. 200mV range specifications are for full scale or greater inputs. For inputs from 20mV
to 200mV, multiply total % of reading error by 10.
[3] For the 20mA, 200mA, 10A ranges, the AC input current from 10% to 120% of range except
where noted. For 1A range, the AC input current from 50% to 120% of range except where
noted.
Measurement Considerations
All frequency counters are susceptible to error when measuring low–voltage, low–frequency signals.
Shielding inputs from external noise pickup is critical for minimizing measurement errors.
Settling Considerations
Errors will occur when attempting to measure the frequency or period of an input following a DC
offset voltage change. The input blocking RC time constant must be allowed to fully settle (up to 1
sec) before the most accurate measurements are possible.
