RIGOL
Service Guide for DM3000 Series
1-18
Capacitance Characteristics
Accuracy Specifications (% of reading + % of range)
[1]
Function
Range
[2]
Test Current
1 Year
23℃±5℃
Temperature
Coefficient
0 ℃ to 18 ℃
28 ℃ to 55 ℃
Capacitance
4.000nF
1uA
2 + 2.5
0.05+0.05
40.00nF
10uA
1 + 0.5
0.05+0.01
400.0nF
10uA
1 + 0.5
0.01+0.01
4.000uF
1mA
1 + 0.5
0.01+0.01
40.00uF
1mA
1 + 0.5
0.01+0.01
200.0uF
1mA
1 + 0.5
0.01+0.01
Notes：
[1] Specifications are for 60 minute warm–up using Math Null. Additional errors may occur for
non–film capacitors.
[2] Specifications are for 1% to 120% of range on the 4nF range and 10% to 120% of range on all
other ranges.
