can adequately output).
Table 2-7 Frequency gain test items
Signal
Virtual
Value
Signal
Frequency
Quick
Test
[1]
Range
Allowable Error Range
24 hours
90 days
1 year
20mV
98Hz
200 mV
±4.9mHz
±5.88mHz
±6.86mHz
200mV
500kHz
Q
2 V
±25Hz
±30Hz
±35Hz
Remark:
[1] Q denotes the optional quick test point.
5. To test the capacitance gain:
(1) Make sure you have carefully read the “Test Conditions”.
(2) Switch to Capacitance measurement and select a range listed in the table
below.
(3) Connect one end of a shielded cable to the input terminal of the meter and
leave the other end free, then enable the REL operation.
(4) Connect the other end to the calibrator.
(5) Input signals in accordance with the table below using the calibrator and
compare the results with the limits from the table (make sure the calibrator
can adequately output).
(6) Repeat step 2, 3, 4 and 5 to finish the test.
Table 2-8 Capacitance test items
Range
[1]
Test Signal Quick Test
[2]
Allowable Error Range
1 year
2.000nF
2nF
Q
±90pF
20.00nF
20nF
±260pF
200.0nF
200nF
±2.6nF
2.000uF
2uF
±26nF
20.00uF
20uF
±260nF
200.0uF
200uF
±2.6μF
2.000mF
2mF
±26μF
20.00mF
20mF
Q
±260μF
100.0mF
100mF
±3.2mF
Remarks:
[1] Specifications under the REL operation.
[2] Q denotes the optional quick test point.
