Programming Guide for DS1000/DS1000CA Series
2-19
Measurement commands
Measurement system commands are the fundamental measurement operations.
These commands are only for the analog channel measurement, and the
measurement results are expressed in scientific numeric notation.
Measurement Commands include:
 :MEASure:CLEar
 :MEASure:VPP?
 :MEASure:VMAX?
 :MEASure:VMIN?
 :MEASure:VAMPlitude?
 :MEASure:VTOP?
 :MEASure:VBASe?
 :MEASure:VAVerage?
 :MEASure:VRMS?
 :MEASure:OVERshoot?
 :MEASure:PREShoot?
 :MEASure:FREQuency?
 :MEASure:RISetime?
 :MEASure:FALLtime?
 :MEASure:PERiod?
 :MEASure:PWIDth?
 :MEASure:NWIDth?
 :MEASure:PDUTycycle?
 :MEASure:NDUTycycle?
 :MEASure:PDELay?
 :MEASure:NDELay?
 :MEASure:TOTal
 :MEASure:SOURce
We will give specific explanations for each command in the following part.
NOTE: A 1kHz, 5Vpp square wave input is used as example for the
following commands.
