RIGOL
© 2008 RIGOL Technologies, Inc.
Programming Guide for DS1000/DS1000CA Series
Waveform commands
The waveform command is used to read the waveform data displayed on the
screen of the oscilloscope.
1. :WAVeform:DATA?
Command Format:
:WAVeform:DATA?□[<source>]
Explanation:
This command is to read the waveform data displayed on the screen of the
oscilloscope. <source> is optional, it can be CHANnel1, CHANnel2, DIGital, MATH
or FFT, the default is CHANnel1.
Returned Format:
Query returns 1024 (1K) data.
Example:
:WAVeform:DATA?□CHANnel1 Read the data acquired from the Channel 1:
119,119,119,119,119,119,123,119,123,119,123,119,123,119,123,119,123,119,1
23,119,119,123,123,119,123,119,119,123,119,123,123,119,123,119,123,119,11
9,123,123,119,123,119,123,119,123,119,123,119,123,119,123,119,119,123,123,
119,123,119,119,123,123,119,123,119,119,123,119,123,119,123,123,119,119,1
23,119,123,119,123,123,119,119,123,119,123,123,119,119,123,119,123,123,11
9,123,119,123,119,119,123,123,119,123,119,123,119,123,119,119,123,119,123,
123,119,123,119,123,119,123,119,123,119,123,119,123,119,123,119,123,119,1
19,123,119,123,123,119,123,119,123,119,123,119,123,119,123,119,123,119,11
9,123,119,123,123,119,123,119,123,119,123,119,119,123,123,119,119,123,123,
119,123,119,123,119,123,119,123,119,119,123,123,119,119,123,123,119,123,1
19,123,119,123,119,123,119,123,119,119,123,123,119,123,119,123,119,119,12
3,123,119,123,119,119,123,123,119,123,119,119,123,119,123,119,123,123,119,
123,119,123,119,123,119,123,119,119,123,119,123,123,119,119,123,119,123,1
23,119,123,119,119,123,123,119,123,119,123,119,123,119,123,119,119,123,11
9,123,123,119,123,119,123,119,119,123,123,119,123,119,123,119,119,123,119,
123,119,123,123,119,123,119,123,119,123,119,119,123,123,119,123,119,123,1
19,123,119,119,123,119,123,119,123,119,123,119,123,119,123,123,119,123,11
9,123,119,123,119,123,119,119,123,123,119,123,119,119,123,119,123,123,119,
