RIGOL
© 2006 RIGOL Technologies, Inc.
User‟s Guide for DS1000 Series
4. Key Test:
Press this soft button to run Keyboard Test program and start the keyboard test
routine. The blocks represent the buttons on the front-panel; the rectangular boxes
with two arrows beside represent the knobs on the front-panel; the square boxes
represent the pressing function for the knobs. Test all keys and knobs,
and check the responsiveness of the blocks on the screen.
Note:
1. The corresponding block on the screen will temporary turn into green (Color
models) or white (Mono models) when pressing a key.
2. The blocks will reverse its color to red (Color models) or black (Mono models)
when the corresponding key or knob get pressed, and the color will keep
reversed during the test.
3. Key backlight lamps will be lit one by one to determine if every backlight LED
works well.
4.
Follow
the
prompti
n
g
message
of
"
<<Pres
s
RU
N
‟ Key
Three
Times
t
o
Exit
the
Test>>" to exit the test.
