Rigol DS1000 Series User Manual

RIGOL
© 2006 RIGOL Technologies, Inc.
User‟s Guide for DS1000 Series
1-3
Figure 1-2
Front Panel Controls
Notation definitions in this User’s Guide:
Throughout this manual, notation symbols of buttons and knobs are the same to
those on front-panel.
 A box around the name of the key denotes MENU function buttons on front-panel,
such as Measure.
 ( ) denotes the multi-function knob .
 denotes the two POSITION knobs.
 denotes the two SCALE knobs.
 denotes the LEVEL knob.
 The name with a drop shadow denotes the menu operating key, such as
WAVEFORM soft key in STORAGE menu.
