Measurements
Cursor
Manual
Voltage difference between cursors (∆V)
Time difference between cursors (∆T)
Reciprocal of ∆T in Hertz (1/∆T)
Track
Voltage value for Y-axis waveform
Time value for Y-axis waveform
Auto
Cursors are visible for Automatic Measurement
Auto Measure
Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Overshoot,
Preshoot, Freq, Period, Rise Time, Fall Time, +Width, -Width,
+Duty, -Duty, Delay1→2 , Delay1→2
NOTE:
*Only one input channel is available when Sample rate is 400MSa/s.
**Specification of DS1000xD series Logic Analyzer.
***Different types have different sample rate:
DS1102C, DS1102CD, DS1102M, DS1102MD: 25GSa/s
DS1062C, DS1062CD, DS1062M, DS1062MD: 10GSa/s
DS1042C, DS1042CD, DS1042M, DS1042MD: 5GSa/s
DS1022C, DS1022CD, DS1022M, DS1022MD: 2.5GSa/s
