User‟s Guide for DS1000 Series
5-6
General Specifications
Display
Display Type
5.7 in. (145 mm) diagonal TFT Liquid Crystal
Display
Display Resolution
320 horizontal × RGB× 234 vertical pixels
Display Color
64K color (DS1000C, DS1000CD)
Mono (DS1000M, DS1000MD)
Display Contrast (typical)
150:1
Backlight Brightness(typical)
300 nit
Probe Compensator Output
Output Voltage(typical)
3 Vp-p into ≥1 MΩ load
Frequency(typical)
1KHz
Power
Supply Voltage
100 ~ 240 VAC
RMS
, 45-440Hz, CAT II
Power Consumption
Less than 50VA
Fuse
2A, T rating, 250 V
Environmental
Ambient
Temperature
Operating 10℃~ 40℃
Non-operating -20℃~ +60℃
Cooling Method
Fan force air flow
Humidity
+35℃ or below: ≤90% relative humidity
+35℃~ +40℃: ≤60% relative humidity
Altitude
Operating 3,000 m or below
Non-operating 15,000 m or below
