RIGOL
© 2006 RIGOL Technologies, Inc.
User‟s Guide for DS1000 Series
Use the horizontal knob to change the position of the expanded
portion.
Use the horizontal knob to adjust the Delayed Scan resolution.
To change the main time base, turn off the Delayed Scan mode.
Since both the main and Delayed Scan are displayed; there are half as many
vertical divisions so the vertical scaling is doubled. Notice the changes in the
status bar.
Delayed Scan Shortcut Key:
Delayed Scan function can be activated not only by menu but also by pressing
horizontal knob.
