Page #118 background image
RIGOL
2-92 Copyright ©1998-2008 RIGOL Technologies, Inc.
User’s Guide for DS1000CA Series
Table 2-76 The Cursor menu
Cursor Increment Operation
Cursor A
X
Y
Turn the multifunctional knob (
to move
cursor A horizontally.
Turn the multifunctional knob (
) to move
cursor A vertically.
Cursor B
X
Y
Turn the multifunctional knob (
) to move
cursor B horizontally.
Turn the multifunctional knob (
) to move
cursor B vertically.
NOTE: Cursor could be moved only when the curse function menu is displayed.
5. To get measurement values:
Position of Cursor 1 (Time cursor centered on the midpoint of screen; Voltage cursor
centered on channel ground level).
Position of Cursor 2 (Same as above).
Horizontal space between cursor 1 and 2 (
X): Time between cursors (1/X), units
in Hz, kHz, MHz, GHz.
Vertical space between cursor 1 and 2 (
Y): Voltage between cursors.
NOTE: The values will be automatically displayed on the right upper corner of screen
when the cursor function menu is hidden or displaying other menus.
Key Points
Cursor Y: Cursors Y appear as horizontal lines on the display to measure vertical
parameters. Usually it is used to measure the Volts. When the source is set as
function, the units are assigned to the function.
Cursor X: Cursor X appears as vertical lines on the display to measure horizontal
parameters. Usually it indicates the time of trigger excursion. When the source is
set as FFT, X means frequency.
