RIGOL Chapter 7 Protocol Decoding
7-4 DS1000Z-E User Guide
change trend of the bus data will be displayed in vector mode.
9. Polarity
Press Polarity to select the data polarity.
10. Decoding Configuration
Press Configure to enter the decoding configuration submenu.
 Press Label to enable or disable the label display function. When "ON" is
selected, the bus label will be displayed at the upper left of the bus (the bus
display is turned on).
 Press Line to enable or disable the bus display function. When "ON" is
selected, the bus will be displayed on the screen. You can use "Pos" to
adjust the vertical display position of the bus.
 Press Format to enable or disable the format display function. When "ON" is
selected, the current bus display format will be displayed on the right side of
the label display (the bus display is turned on). You can use "Format" to set
the display format of the bus.
 Press Width to enable or disable the width display function. When "ON" is
selected, the current bus width will be displayed on the right side of the
format display (the bus display is turned on). You can use "Width" to set the
bus width.
 Dig.Sa menu displays the current digital sample rate which relates to the
data source selected currently. When the data source is "Trace", the digital
sample rate relates to the horizontal time base.
Note: By default, DS1000Z-E uses "Trace" as the data source.
11. Event Table
The event table displays the decoded data and the corresponding line number
and time in table format. It can be used to observe relatively longer decoded
data. Press Evt.Table  EventTable to select "ON" (Note: This operation is
only available when MATH  Decode1 / Decode2  Decode is set to "ON")
to enter the event table interface as shown in Figure 7-2.
Format: set "Data" display format in the event table to HEX, DEC or ASC.
Focus: press this key and turn to browse the "Data" item.
View: select the display form of the event table. If "Packets" is selected, the
time and data are displayed in the event table; if "Details" is selected, the
detailed data of the specified row will be displayed in the event table; if
"Payload" is selected, all data of the specified column will be displayed in the
event table. When different view is selected, the export format of the data table
will change accordingly.
Data: select the data column to be viewed in the "Details" or "Payload" view. It
is valid for the decoder of multiple data output.
