Chapter 12 Store and Recall RIGOL
DS1000Z-E User Guide 12-3
waveforms will be displayed on the screen.)
3. Waves
Save the main setting information (e.g. "On/Off" states of the channels, vertical
scale and horizontal scale) and waveform data of all enabled channels (analog
channel) to the external memory in "*.wfm" format. When the waves file is
loaded, the system will set the oscilloscope based on its existing saved setting
information of the oscilloscope and recall all the waveform data. When the
loading is complete, the oscilloscope will be in the "STOP" state. Under such
situation, you can adjust the waveform display by changing the setting (such as
the horizontal scale and vertical scale) of the oscilloscope; or you can adopt the
one-key measurement or cursor measurement to measure the waveform
parameters.
Note:
 The reading and saving operations of the file in ".wfm" format can only be
completed on the oscilloscope.
 If you set the oscilloscope to be in the "RUN" state, the oscilloscope will
start over the waveform sampling. (That means, the loaded waveform data
will be cleared.)
4. Setups
Save the settings of the oscilloscope to internal or external memory in "*.stp"
format. The stored settings can be recalled.
5. CSV
Save the screen waveform data of all enabled channels (analog channel) or the
memory data of the specified enabled channels to the external memory in
"*.csv" format. You can specify the file name and the saving directory and save
the corresponding parameter file (*.txt) under the same directory using the
same file name. This parameter file is the same as the "Parameters" function.
The recall of CSV and parameter files is not supported.
After selecting this type:
Press DataSrc to select "Screen" or "Memory". After selecting "Memory", press
Channel to select the desired channel (Note: Only channels currently enabled
can be selected).
Press Param to enable or disable the parameter save function.
Press Sequence to choose whether to add sequence numbers for the waveform
points in the CSV file. You can select "ON" or "OFF" and the default is "ON"
(namely add the sequence number).
6. Parameters
Save the parameters of the screen waveform to the external memory in "*.txt"
format. The parameter storage contains the system information (such as the
