Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-115
:TRIGger:DELay:TUPPer
Syntax :TRIGger:DELay:TUPPer <NR3>
:TRIGger:DELay:TUPPer?
Description
Set or query the upper limit of the delay time in delay trigger. The default unit is s.
Parameter
Name
Type
Range
Default
<NR3>
Real
16ns to 10s
2μs
Explanation This command is only available when the delay type (refer to :TRIGger:DELay:TYPe) is
LESS, GOUT or GLESs.
Return
Format
The query returns the upper limit of the delay time in scientific notation.
Example
:TRIGger:DELay:TUPPer 0.002 /*Set the upper limit of the delay time to 2ms*/
:TRIGger:DELay:TUPPer? /*The query returns 2.000000e-03*/
Related
Command
:TRIGger:DELay:TYPe
:TRIGger:DELay:TLOWer
Syntax :TRIGger:DELay:TLOWer <NR3>
:TRIGger:DELay:TLOWer?
Description
Set or query the lower limit of the delay time in delay trigger. The default unit is s.
Parameter
Name
Type
Range
Default
<NR3> Real
Related to the delay type:
GREater: 8ns to 10s
GOUT or GLESs: 8ns to 9.99s
1μs
Explanation This command is only available when the delay type (refer to :TRIGger:DELay:TYPe) is
GREater, GOUT or GLESs.
Return
Format
The query returns the lower limit of the delay time in scientific notation.
Example
:TRIGger:DELay:TLOWer 0.002 /*Set the lower limit of the delay time to 2ms*/
:TRIGger:DELay:TLOWer? /*The query returns 2.000000e-03*/
Related
Commands
:TRIGger:DELay:TYPe
:TRIGger:DELay:TUPPer
