Rigol DS1000Z Series

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-117
:TRIGger:SHOLd:PATTern
Syntax :TRIGger:SHOLd:PATTern <pattern>
:TRIGger:SHOLd:PATTern?
Description
Set or query the data type in setup/hold trigger.
Parameter
Name
Type
Range
Default
<pattern> Discrete {H|L} H
Explanation H: high level
L: low level
Return
Format
The query returns H or L.
Example
:TRIGger:SHOLd:PATTern L
:TRIGger:SHOLd:TYPe
Syntax :TRIGger:SHOLd:TYPe <type>
:TRIGger:SHOLd:TYPe?
Description
Set or query the setup type in setup/hold trigger.
Parameter
Name
Type
Range
Default
<type> Discrete {SETup|HOLd|SETHOLd} SETup
Explanation  SETup: set the time that the data stays stable and constant before the clock edge
appears (
:TRIGger:SHOLd:STIMe).
 HOLd: set the time that the data stays stable and constant after the clock edge
appears (
:TRIGger:SHOLd:HTIMe).
 SETHOLd: set the time that the data stays stable and constant before and after the
clock edge appears (:TRIGger:SHOLd:STIMe and :TRIGger:SHOLd:HTIMe).
Return
Format
The query returns SET, HOL or SETHOL.
Example
:TRIGger:SHOLd:TYPe SETHOLd
Related
Commands
:TRIGger:SHOLd:HTIMe
:TRIGger:SHOLd:STIMe
