12 DS1000Z Quick Guide
Logic Analyzer
Press this key to open the logic analyzer control menu. You can
turn on or off any channel or channel group, modify the display
size of the digital channel, modify the logic threshold of the
digital channel as well as group the 16 digital channels. You
can also set a label for each digital channel.
Note:
― This function is only applicable to DS1000Z Plus with the MSO upgrade option.
― Press LA  D7-D0; when "On" is selected, CH4 function is automatically
disabled; when "Off" is selected, CH4 function recovers automatically. Press LA
 D15-D8; when "On" is selected, CH3 function is automatically disabled;
when "Off" is selected, CH3 function recovers automatically.
Signal Source
Press this key to enter the source setting interface. You can
enable or disable the output of the [Source1] or [Source2]
connector on the rear panel, set the output signal waveform
and parameters, turn on or off the state display of the current
signal.
Note: This function is only applicable to digital oscilloscopes with source channels.

Rigol DS1054 Specifications

General

Bandwidth	50 MHz
Channels	4
Sample Rate	1 GSa/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Display Resolution	800x480 pixels
Interfaces	USB Host, USB Device, LAN
Input Coupling	DC, AC, GND
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope, Alternate
Waveform Capture Rate	30, 000 wfms/s
Input Impedance	1 MΩ ± 2%
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
