20 DS1000Z 快速指南
使用内置帮助系统
本示波器的帮助系统提供了前面板各功能(包括菜单键的说明。 Help 键打开
帮助界面,再次按下则关闭。帮助界面主要分两部分,左边为“帮助选项”,右边为
“帮助显示区”
15 帮助信息
您可以直接按面板上的按键(电源键
、多功能旋钮 和菜单翻页键 /
外)即可在“帮助显示区”中获得相应的帮助信息。
帮助选项
帮助显示区
