General| Bandwidth | 50 MHz |
|---|---|
| Channels | 4 |
| Sample Rate | 1 GSa/s |
| Vertical Sensitivity | 1 mV/div to 10 V/div |
| Timebase Range | 5 ns/div to 50 s/div |
| Vertical Resolution | 8 bits |
| Display Resolution | 800x480 pixels |
| Interfaces | USB Host, USB Device, LAN |
| Input Coupling | DC, AC, GND |
| Display | 7 inch TFT LCD |
| Trigger Types | Edge, Pulse, Video, Slope, Alternate |
| Waveform Capture Rate | 30, 000 wfms/s |
| Input Impedance | 1 MΩ ± 2% |
| Memory Depth | 24 Mpts (Single Channel), 12 Mpts (Dual Channel) |
