Rigol DS1054 User Manual

RIGOL
VI DS1000Z Quick Guide
Environmental Considerations
The following symbol indicates that this product complies with the WEEE Directive
2002/96/EC.
Product End-of-Life Handling
The equipment may contain substances that could be harmful to the environment or
human health. To avoid the release of such substances into the environment and
avoid harm to human health, we recommend you to recycle this product
appropriately to ensure that most materials are reused or recycled properly. Please
contact your local authorities for disposal or recycling information.
Document Overview
This manual is used to guide users to quickly get familiar with the front panel, rear
panel, user interface and basic operation method of DS1000Z series digital
oscilloscope. You can download the newest version of the manual from RIGOL
official website (www.rigol.com).
Format Conventions in this Manual:
1. Key
The front panel keys are denoted by the format of "Key Name (Bold) + Text Box".
For example, Utility denotes the "Utility" key.
2. Menu
The menu softkeys are denoted by the format of "Menu Word (Bold) +
Character Shading". For example, System denotes the "System" menu under
Utility.
3. Operation Step
The next step of operation is denoted by an arrow "". For example, Utility 
System denotes that first press Utility on the front panel and then press
System.

Rigol DS1054 Specifications

General

Bandwidth	50 MHz
Channels	4
Sample Rate	1 GSa/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Display Resolution	800x480 pixels
Interfaces	USB Host, USB Device, LAN
Input Coupling	DC, AC, GND
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope, Alternate
Waveform Capture Rate	30, 000 wfms/s
Input Impedance	1 MΩ ± 2%
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
