Rigol DS1054 User Manual

RIGOL
DS1000Z Quick Guide
VII
4. Knob
Label Knob
HORIZONTAL SCALE
Horizontal Scale Knob
HORIZONTAL POSITION
Horizontal Position Knob
VERTICAL SCALE
Vertical Scale Knob
VERTICAL POSITION
Vertical Position Knob
TRIGGER LEVEL
Trigger Level Knob
Content Conventions in this Manual:
DS1000Z series includes the following models. Unless otherwise noted, this manual
takes DS1104Z-S Plus as an example to illustrate the front panel, rear panel, user
interface and basic operation methods of DS1000Z series.
Model
Analog
Bandwidth
Number of
Analog
Channels
Number of
Source
Channels
Number of
Digital
Channels
DS1104Z-S Plus
100 MHz
4
2
16
[1]
DS1074Z-S Plus
70 MHz
4
2
16
[1]
DS1104Z Plus
100 MHz
4
--
16
[1]
DS1074Z Plus
70 MHz
4
--
16
[1]
DS1054Z
50 MHz
4
--
--
Note
[1]
: Required to upgrade through the MSO upgrade option (includes the logic analyzer probe
RPL1116 and the model label).

Rigol DS1054 Specifications

General

Bandwidth	50 MHz
Channels	4
Sample Rate	1 GSa/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Display Resolution	800x480 pixels
Interfaces	USB Host, USB Device, LAN
Input Coupling	DC, AC, GND
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope, Alternate
Waveform Capture Rate	30, 000 wfms/s
Input Impedance	1 MΩ ± 2%
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
