RIGOL
20 DS1000Z Quick Guide
Source1 Waveform.
When the impedance of signal source is set to 50 Ω,
will be displayed at
the bottom of the Source1 Waveform.
Only applicable to digital oscilloscopes with source channels.
20. Source2 Waveform
Display the type of waveform currently set for Source2.
When the modulation is enabled,
will be displayed at the bottom of the
Source2 Waveform.
When the impedance of signal source is set to 50 Ω,
will be displayed at
the bottom of the Source2 Waveform.
Only applicable to digital oscilloscopes with source channels.
21. Notification Area
Display sound icon and USB disk icon.
Sound Icon: Press Utility Sound to enable or disable the sound. When
the sound is enabled, will be displayed; when the sound is disabled,
will be displayed.
USB Disk Icon: when a USB disk is detected,
will be displayed.
22. Operation Menu
Press any softkey to activate the corresponding menu.
The following symbols might be displayed in the menu:
Denote that you can rotate the multifunction knob to modify
parameters. The backlight of turns on during the parameter
Denote that you can rotate to select the desired item, the item
currently selected is displayed in blue, press down the knob to enter the
corresponding menu. The backlight of
is constant on after menus
with this symbol are selected.
Denote that press to input desired paramrter values directly using
the pop-up numeric keyboard. The backlight of is constant on after
menus with this symbol are selected.
Denote that the current menu has several options.
Denote that the current menu has a lower level menu.
Press this key to return to the previous menu.
The number of the dots denotes that the number of the pages the
current menu has.
To Next Page
