RIGOL Chapter 6 MATH and Measurement
6-10 MSO1000Z/DS1000Z User’s Guide
Tips
 You can adjust the center frequency and horizontal scale at the same time
using HORIZONTAL
SCALE.
 Signals with DC components or deviation would cause error or deviation of the
FFT waveform components. To reduce the DC components, set the "Channel
Coupling" to "AC".
 To reduce the random noise and aliasing frequency components of repetitive
or single pulse, set the "Acquisition Mode" of the oscilloscope to "Average".
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
