RIGOL Chapter 13 Signal Source

13-6 MSO1000Z/DS1000Z User’s Guide

To Output Noise

Press Src1Conf to open the waveform setting menu. Press Wave and select "Noise".

At this point, you can output a noise signal with the specified amplitude, offset and

impedance.

1. Source 1 output

Press Output to turn on or off the signal output.

2. Set the amplitude

Press Amplitude to set the amplitude of the signal. For the setting method,

please refer to the introduction in "

Parameter Setting Method". When the

impedance is set to HighZ, the range is from 20 mVpp to 5 Vpp; when the

impedance is set to 50 Ω, the range is from 10 mVpp to 2.5 Vpp.

3. Set the offset

Press Offset to set the DC offset of the noise signal. For the setting method,

please refer to the introduction in "

Parameter Setting Method". When the

impedance is HighZ, the range is from (-2.5 V + the current amplitude/2) to (2.5

V - the current amplitude/2); when the impedance is set to 50 Ω, the range is

from (-1.25 V + the current amplitude/2) to (1.25 V - the current amplitude/2).

To Output Built-in Waveform

MSO1000Z/DS1000Z series oscilloscope provides 7 kinds of built-in waveforms,

including Sinc, ExpRise, ExpFall, ECG, Gauss, Lorentz and Haversine. Press

Src1Conf to open the waveform setting menu. Press Wave and select "Built-in". At

this point, you can set the output signal parameters according to the type of the

built-in waveform selected.

1. Source 1 output

Press Output to turn on or off the signal output.

2. Select built-in waveform

Press Built-In to select any of the 7 built-in waveforms (as shown in the figures

below).
