DC Gain
Accuracy
<10 mV: ±4% full scale
≥10 mV: ±3% full scale
DC Offset
Accuracy
±0.1 div±2 mV±1% offset value
Channel to
Channel
Isolation
DC to maximum bandwidth: >40 dB
Vertical (Digital Channel) (Applicable to MSO1000Z and DS1000Z Plus
with MSO Upgrade Option)
Threshold Adjustable threshold of 8 channels per group
Threshold
Selection
TTL (1.4 V)
5.0 V CMOS (+2.5 V), 3.3 V CMOS (+1.65 V)
2.5 V CMOS (+1.25 V), 1.8 V CMOS (+0.9 V)
ECL (-1.3 V)
PECL (+3.7 V)
LVDS (+1.2 V)
0 V
User
Threshold
Range
±15.0 V, 10 mV step
Threshold
Accuracy
±(100 mV+3% threshold setting)
Dynamic Range
±10.0 V + threshold
Minimum
Voltage Swing
500 mVpp
Vertical
Resolution
1 bit
Trigger
Trigger Level
Range
± 5 div from center of the screen
Trigger Mode Auto, Normal, Single
Holdoff Range
16 ns to 10 s
High Frequency
Rejection
[1]
75 kHz
Low Frequency
Rejection
[1]
75 kHz
Trigger
Sensitivity
[1]
1.0 div (below 5 mV or noise rejection is enabled)
0.3 div (above 5 mV and noise rejection is disabled)
Edge Trigger
Edge Type
Rising, Falling, Rising/Falling
Pulse Trigger
