Chapter 18 Specifications RIGOL
MSO1000Z/DS1000Z User’s Guide 18-7
Standard
Waveform
Sine, Square, Pulse, Ramp, Noise, DC
Built-in
Waveform
Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, Lorentz,
Haversine
Sine Frequency Range 0.1 Hz to 25 MHz
Flatness ±0.5 dB (relative to 1 kHz)
Harmonic
Distortion
-40 dBc
Stray
(Non-harmonic)
-40 dBc
Total Harmonic
Distortion
1%
S/N Ratio
40 dB
Square/Pulse Frequency Range Square: 0.1 Hz to 15 MHz
Pulse: 0.1 Hz to 1 MHz
Rise/Fall Time
<15 ns
Overshoot <5%
Duty Cycle Square: always be 50%
Pulse: 10% to 90% adjustable
Duty Cycle
Resolution
1% or 10 ns (the larger of the two)
Min. Pulse Width
20 ns
Pulse Width
Resolution
10 ns or 5 bits (the larger of the two)
Jitter
500 ps
Ramp Frequency Range 0.1 Hz to 100 kHz
Linearity 1%
Symmetry
0 to 100%
Noise
[1]
Bandwidth
25 MHz
Built-in
Waveform
Frequency Range
0.1 Hz to 1 MHz
Arbitrary
Waveform
Frequency Range
0.1 Hz to 10 MHz
Waveform Length
2 to 16k points
Frequency Accuracy 100 ppm (lower than 10 kHz)
50 ppm (higher than 10 kHz)
Resolution
0.1 Hz or 4 bits, the larger of the two
Amplitude Output Range 20 mVpp to 5 Vpp, HighZ
10 mVpp to 2.5 Vpp, 50 Ω
Resolution
100 μV or 3 bits, the larger of the two
Accuracy 2% (1 kHz)
DC Offset Range ±2.5 V, HighZ
±1.25 V, 50 Ω
Resolution 100 μV or 3 bits, the larger of the two
Accuracy 2% (1 kHz)
