RIGOL Chapter 2 Command System
2-194 MSO1000Z/DS1000Z Programming Guide
:TRIGger:DELay:TYPe
:TRIGger:DELay:TYPe <type>
:TRIGger:DELay:TYPe?
Set or query the delay type in delay trigger.
{GREater|LESS|GLESs |GOUT}
 GREater: trigger when the time difference (△T) between the specified edges of tigger
source A and tigger source B is greater than the preset time limit.
 LESS: trigger when the time difference (△T) between the specified edges of tigger
source A and tigger source B is lower than the preset time limit.
 GLESs: trigger when the time difference (△T) between the specified edges of tigger
source A and tigger source B is greater than the lower limit of the preset time and
lower than the upper limit of the preset time. Note that the time lower limit must be
lower than the time upper limit.
 GOUT: trigger when the time difference (△T) between the specified edges of tigger
source A and tigger source B is lower than the lower limit of the preset time or
greater than the upper limit of the preset time. Note that the time lower limit must be
lower than the time upper limit.
The query returns GOUT, GRE, LESS, or GLES.
:TRIGger:DELay:TYPe GOUT /*Set the delay type to ><*/
:TRIGger:DELay:TYPe? /*The query returns GOUT*/
:TRIGger:DELay:TUPPer
:TRIGger:DELay:TLOWer
:TRIGger:DELay:TUPPer
:TRIGger:DELay:TUPPer <NR3>
:TRIGger:DELay:TUPPer?
Set or query the upper limit of the delay time in delay trigger. The default unit is s.
This command is only available when the delay type (refer to :TRIGger:DELay:TYPe) is
LESS, GOUT, or GLESs.
The query returns the upper limit of the delay time in scientific notation.
:TRIGger:DELay:TUPPer 0.002 /*Set the upper limit of the delay time to 2ms*/
:TRIGger:DELay:TUPPer? /*The query returns 2.000000e-03*/
