Chapter 1 Disassemble and Assemble RIGOL
MSO1000Z/DS1000Z Service Guide 1-1
Chapter 1 Disassemble and Assemble
Disassemble and Assemble Notices
Notices:
 Do not disassemble the instrument unless for working requirement.
 Only authorized personnel can disassemble the instrument.
 Cut off the power supply before disassembling the instrument.
 Please wear anti-static wrist strap or make other anti-static precaution when
disassembling the instrument.
 Please use proper tools and follow the correct steps.
 Take care not to deform the metal structure and be scuffed when disassembling
the metal structures.
Tools Required:
 Phillips screwdriver T10
 BNC socket
 5mm hexagon socket
WARNING
Make sure that the power supply is cut off before disassembling the
instrument. Only personnel with relative training or relative qualification
certification can disassemble the instrument.

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
