RIGOL Chapter 1 Disassemble and Assemble
1-6 MSO1000Z/DS1000Z Service Guide
Tip:
 Pay attention to the connecting positions of the power cord and fan cable
before removing them to avoid incorrect connection or incomplete
connection when assembling the instrument.

Check whether the screen line and the keyboard cable on the main board are
correctly installed before assembling the rear metal cover.

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
