Rigol DS2000E Series Quick Guide

RIGOL
DS2000E Quick Guide 11
English
To Connect the Probe
RIGOL's DS2000E series is equipped with a passive probe. For details about
the models of the probe, refer to DS2000E DataSheet . For detailed technical
information of the probes, please refer to the corresponding Probe User’s
Guide.
To Connect the Probe:
1. Connect the BNC terminal of the probe to an analog channel input of the
oscilloscope at the front panel.
2. Connect the ground alligator clip of the probe to the circuit ground
terminal and then connect the probe tip to the circuit point under test.
Figure 6 To Connect the Probe
