Product Overview
Based on the UltraVision technology, DS2000E is a digital oscilloscope with high
performance. It is equipped with extremely high memory depth, wide dynamic
range, superb waveform capture rate, and comprehensive trigger functions. It
also features hardware waveform recording function and good display effects.
As a rare debugging instrument, it has been widely applied to various industries
and fields, such as communications, aerospace, defense, embedded systems,
computers, research, and education. It is the excellent representative of the
200 MHz digital oscilloscope type with the most comprehensive functions and
excellent specifications.
For descriptions of the front panel, refer to Figure 1 and Table 1; for
descriptions of the rear panel, refer to Figure 2 and Table 2; and for
descriptions of the main interface (display screen), refer to Figure 3 and Table
3.
Figure 1 Front Panel
1 2 3 4 5 6 7 8 9 10
