Rigol DS2000E Series Quick Guide

RIGOL
DS2000E Quick Guide 7
English
Table 1 Front Panel Description
No.
Description
No.
Description
1 Measurement Menu Softkeys 11
Compensation Signal Output
Terminal/Ground Terminal
2 LCD 12
External Trigger Input
Terminal
3 Multi-function Knob 13 Trigger Control Area
4 Function Keys 14
Waveform
Recording/Playback Keys
5 Navigation Knob 15
Analog Channel Input
Terminals
6 Clear Key 16 Vertical Control Area
7 AUTO Key 17 Function Menu Softkeys
8 Run/Stop Key 18 Horizontal Control Area
9 Single Trigger Control Key 19 USB HOST Interface
10
Help/Print Key
20
Power Key
Figure 2 Rear Panel
1 2 3
7 6 5 4
