RIGOL
8 DS2000E Quick Guide
English
Table 2 Rear Panel Description
No.
Description
1
Handle
2
LAN Interface
3
USB DEVICE Interface
4
Trigger Output Interface
5
Lock Hole
6
Fuse
7
AC Power Cord Connector
Figure 3 User Interface
1 2 3 4 5 6 7 8 9 10
15 14 13 12
11
