RIGOL Chapter 1 Quick Start
1-8 DSG800 User's Guide
7. Direction Keys/Step Key
When setting a parameter, Step is used to set the step of
the parameter currently selected; the direction keys are
used to enter the parameter editing state and move the
cursor to the specified digit.
For the storage function, the direction keys are used to
collapse and expand the directory currently selected.
When editing a filename, the direction keys are used to
select the desired character.
In the parameter information display interface, the
direction keys are used to switch the parameter tabs.
It is used to turn on or off the RF signal generator. You can
use the following method to enable or disable this key.
Press Syst Pwr Status to select "Default" or "Open".
When "Default" is selected, you need to press this key to
start the instrument after the instrument is powered on.
When "Open" is selected, the instrument will start
automatically after it is powered on.
Besides, this key provides the delayed switching function
(namely, the instrument can be turned on or off only
when you press this key and hold it down for a certain
period of time) to avoid the shut-down of the instrument
Store and recall various types of files (such as the
instrument state). For the detailed information, refer to
"
Store and Recall".
10. System Setting Key
Set the system-related parameters. For the detailed
information, refer to "To Set the System Parameters".
