RIGOL Chapter 1 Quick Start
1-10 DSG800 User's Guide
14. LF Output Connector
When the LF output is turned on, this connector is used to
output the LF signal.
15. RF Output Connector
When the backlight of RF/on is illuminated, this
connector is used to output the RF signal and RF sweep
signal.
When the backlights of RF/on and Mod/on are both
illuminated, this connector is used to output the RF
CAUTION
To avoid damaging the instrument, the reverse DC voltage on the
RF output connector cannot exceed 50 V and the reverse power
cannot exceed +30 dBm (1W) in the 1 MHz to 3 GHz frequency
