The RF modulation output
is not turned on and only
AM is turned on.
The RF modulation
output is turned on and
AM is turned on.
The RF modulation output
is not turned on and only
FM is turned on.
The RF modulation
output is turned on and
FM is turned on.
The RF modulation output
is not turned on and only
ØM is turned on.
The RF modulation
output is turned on and
ØM is turned on.
The RF modulation output
is not turned on and only
Pulse is turned on.
The RF modulation
output is turned on and
Pulse is turned on.
The RF modulation output
is not turned on; AM and
FM are turned on.
The RF modulation
output is turned on; AM
and FM are turned on.
The RF modulation output
is not turned on; AM and
ØM are turned on.
The RF modulation
output is turned on; AM
and ØM are turned on.
The RF modulation output
is not turned on; AM and
Pulse are turned on.
The RF modulation
output is turned on; AM
and Pulse are turned on.
The RF modulation output
is not turned on; FM and
Pulse are turned on.
The RF modulation
output is turned on; FM
and Pulse are turned on.
The RF modulation output
is not turned on; ØM and
Pulse are turned on.
The RF modulation
output is turned on; ØM
and Pulse are turned on.
The RF modulation output
is not turned on; AM, FM
and Pulse are turned on.
The RF modulation
output is turned on; AM,
FM and Pulse are turned
on.
The RF modulation output
is not turned on; AM, ØM
and Pulse are turned on.
The RF modulation
output is turned on; AM,
ØM and Pulse are turned
on.
The RF modulation output
is not turned on and none
of the modulation functions
is turned on.
-- --
Tip: Press MOD and the AM/FM/ØM/PUL modulation icons are displayed in the
function status area. If a modulation function is turned on (or off), the
corresponding icon will be illuminated (or grayed out).
