Cleaning flue pipes
The flue pipes should be cleaned at least 2 x a year or after approx. 700 kg
pellets. The flues are behind the combustion chamber.
Remove the hexagonal screws of both covers at the rear side.
Now you can remove the covers.
Loose the screws of the heat exchanger lids and remove them.
Clean the heat exchangers with the provided brush.
Dismantle the two cleaning covers behind the ash drawer by loosening the 4
milled nuts.
Vacuum out the chambers in the lower section of the flue pipes.
Also clean the impeller of the flue gas blower by vacuuming out the suction
opening.
Re-assembly the parts removed in reverse order.
Note
Your stove may suck in false air via incorrectly sealed cleaning covers; this
air may lead to incomplete combustion in the fire trough and thus piling up of
pellets. DANGER of FIRE!
To ensure the proper operation of your pellet stove, replace the defect
(porous, frayed) seals after cleaning and maintenance.
Cleaning the convection air openings
Vacuum clean any dust deposits from the convection air openings at regular
intervals.
The stove should be cleaned thoroughly prior to the start of the heating season
to prevent excess odour.
Cleaning the door glass
The viewing window becomes coated in the case of solid fuels, particularly with
the very fine ash of wood pellets, light or dark depending on the pellet quality
(especially with low output). This is a natural process and does not constitute a
defect. The glass can be cleaned best with a moist cloth. Stubborn dirt can be
removed with a special cleaner available from your stove dealer. Usual cleaners
containing acid or solvents can be too harsh and damage the glass.
Cleaning of painted surfaces
Wipe of the painted surfaces with a damp cloth, do not scrub. Do not use
solvent-containing cleaners.
