Spare part overview article numbers
Nr. Art.Nr.: Description
1 L01961 Ash drawer
2 B16578
Container lid metallic
grey cpl.
B16971 Container lid black cpl.
3 N112309
Pressure spring door
contact
4 B16576 Cover metallic
B16965 Cover cpl., black
E15143 Cover AH metallic
E15356 Cover AH black
6 N110461 Double ball catch
7 N108131 Pressure spring
8 Z34464 Insertion screw
L02250 Bearing holding plate
9 Z34790 Electromagnet
10 N103693
Culimeta flat packing
black 8x2
11 N111538 Spring plug
12 Z34411 Fire brick rear left
13 Z34410 Fire brick rear right
14 Z34409 Fire brick rear
15 Z34412 Fire brick front left
16 Z34413 Fire brick front right
17 Z34478 Door metallic grey
Z34979 Door black
B16564 Door metallic complete
B16972 Door compleet, black
18 B16565 Door handle complete
19 B16568 Front top metallic
B16961 Front top black
20 B15248 Sensor tube
21 L02007 Guide stone
22 B16464
Transmission air
regulator
23 N111058 Setscrew with pin
24 L00475 Glass holder
25 B16798 Handle burnback flap
26 N111731 Container seal
27 B16561 Mainboard USB11
28 N111695 Height adjustment screw
29 Z34554 Wood retainer
30 Z34479
Cable cover metallic
grey
Z34967 Cable cover black
31 Z34557 Chain dump grate
Z35158
Spacer chain guide /
clamping plate
Z35302 Chain guide
Z35303 Clamping plate
32 B16553 Sprocket top
Z34824 Bearing clamping plate
33 B16555 Sprocket bottom
35 Z11915
Lock ring conveyer
screw
36 Z21690 Cooking cover
37a B16679 Convection cover
37b Z35555 Angle bracket
38 Z34467
Coupling dump grate
motor
39 Z34461 Bearing plate bottom
40 Z34757 Bearing plate top
B16708
Bearing & sprocket
complete
Nr. Art.Nr.: Description
41 N111732
Magnetic switch upper
section
N111733
Solenoid switch lower
part
42 L01875 Driving plate dump grate
43 Z34242 Fire trough
44 L02008 Fire trough tray
45 L02044 Holder dump grate
46 B16680 Cleaning cover
47 N111883
Milled nut (cleaning
cover)
48 Z30137
Flue pipe attachments
(without seal) metallic
grey
Z20556
Flue pipe connection
black 150mm
49 N111320
Sealing cord grey
Ø14mm
50 N111320
Sealing cord grey
Ø14mm
51 B16681 Flue gas flap
52 B16682 Flue gas chute lid
53 N111825 Door contact switch
54 Z34244 Dump grate
55 N111880 Dump grate motor
56 B16577
Flue pipe cover metallic
grey
B16966 Flue pipe cover black
57 B16683
Burnback flap
assembled
58 Z34486
Rear wall left metallic
grey
Z34971 Rear panel left black
59 Z34487
Rear wall right metallic
grey
Z34970 Rear panel right, black
60 N111631
Round sealing cord grey
Ø6mm
61 N111581
Induced draught fan
motor
62 N111637 Setscrew door handle
63 B16559
Setscrew dump grate
contact
64 Z34457 Hinge
65 Z34472 Hinge plate
66 Z34529 Torsion spring
67 N110461 Double ball catch
68 Z34463 Discharge auger
69 N111862 Screw motor, stepless
70 N111862 Screw motor, stepless
71 N111817 Air regulator motor
72 N107887 Fuse holder
73 Z35182 Plastic bearing
74 N108310 Sinter bearing ID10
75 Z34555
Sinter bearing ID 10,2
sprocket out
76 Z34553 Disc air deflector
77 N111586
Safety temperature
limiter
78 Z34565 Stone option side
79 Z34483 Soapstone front
Z35078 Sandstone front
Z36340
Quartz front anthracite
grey
Z36545 Frontstone white
Nr. Art.Nr.: Description
80 L01966 Stone holder stone front
81 L02009 Stone holder stone side
82 B16566
Side panels steel
metallic grey left
B16964 Left side panel black
83 B16572
Side panels steel
metallic grey right
B16963 Right side panel black
84 B16676
Flame temperatur probe
Induo
85 B16574 Touch-Display
86 Z34303
Door glass (ceramic
glass)
87 L02010 Door lock
88 B16570 Bottom cover panel
89 L01957 Closure plate
90 N104718 Shaft securing device
91 B16797 Ceramic ignition
93 Z34480 Deflector
94 B16547 Air regulator
95 B16030 Add. board mot. hor.
96 B16671 Add. board mot. vert.
97 B16672 Add. board fluegas flap
98 Z33924
Intermediate shaft dump
grate
99 N111798
Cylindrical pin door
handle
Z35018
Cable 2m for touch-
display
B16581 Cabletree
B17365
Upgrade kit bearing
insertion screw
100 *1 N110032 Hexagonal screw
101 *1 N103964
Hexagonal screw
M06x16
102 *1 N100172 Washer
103 *1 L02250 Bearing holding plate
104 *1 L02605 Bearing collar plate
105 L02604 Motor plate
106 *1 Z35750 Bearing support
107 *2 N111967 Allen screw M06x10
108 *2 Z35752 Bearing retaining ring
109 Z34468 Sealing
110 Z35163 Sealing
*3 B17843 Kit fluegas flap black
*3 B17844
Kit fluegas flap metallic
grey
111 B17845 Flap handle black
B17095 Flap handle metallic grey
112 Z36535 Shaft of fluegas flap
113 B16675 Flap lever flue gas flap
114 N112283 Hexagonal screw
115 N111058 Setscrew with pin
116 Z34471
Tension spring flue gas
flap
117 Z18997 Rubber buffer
*1
from serial number
1297483
*2
not included in upgrade
kit B17365
*3
The set is to be ordered
up to serial number
1354182, from serial
number 1354183 you
can order in parts
