16
“HOLD” flashes for 3 seconds and quenches, which means the welding stops. 2 seconds later,
Multifunctional Data Display redisplays the preset current.
Fig.8 The Status after Stop Welding under MIG Mode
3） Operation instruction under LIFT TIG mode.
1 When welding stops, press the Function Switch Key to LIFT TIG mode. The LIFT TIG
indicator light will illuminate (Fig.9).
Fig.9 LIFT TIG Mode
2 Adjusting current:
The welding current can be adjusted the Multifunctional Data Adjusting Knob while welding.
See the chapter “TECHNICAL PARAMETERS” for the range of output current.
The settings will be retained when the machine closed, and displayed when the machine
restarts.
3 The panel displays as Fig.10 when performing welding, the welding voltage is 13.2V, and the
current is 80A. It will go to the default state of welding current in 5 seconds when stopping
welding.
Fig.10 LIFT TIG Mode
