Rinnai Infinity 32e - Dismantling for Service

Infinity REU-V3232W /HD250E REU-V3232WC - 43 - Issue 1 - 8/09/03 ©Rinnai
20. Dismantling for Service
230 volt potential exposure. Isolate the appliance and confirm with a multimeter.
Item Page
1. Removal of the Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
2. Removal of the PCB Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
3. Removal of the Water Flow Sensor, Servo and Bypass Servo . . . . . . . . . . . . . . . . . 44
4. Removal of the Sparkers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5. Removal of the Combustion Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6. Removal of the Hot Water Outlet & Heat Exchanger Outlet Thermistors. . . . . . . 45
7. Removal of the Transformers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8. Removal of the Gas Inlet, Solenoids and Flame Rod . . . . . . . . . . . . . . . . . . . . . . . . 46
9. Removal of the Gas Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
10. Removal of the Heat Exchanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
11. Removal of the Thermal Fuse and OHS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Unless otherwise stated, re-assembly is the reverse of dismantling.
