Rinnai Infinity 32e - Specifications

Infinity REU-V3232W / HD250E REU-V3232WC - 2 - Issue 1 - 8/09/03 ©Rinnai
2. Specifications
Note 1: The default factory setting is 55° C for Infinity 32e and 65° C for HD 70e. The unit can be ordered from Rinnai UK to be pre-set
to any of the other temperatures listed. The unit can be pre-set to any of the temperatures listed by a suitably qualified person.
Controllers are available with default temperatures up to 75° C. When fitted with controllers, only temperatures not exceeding the default
temperatures can be selected. When fitted without controllers, the unit will deliver water at the default temperature. Controllers are not available
with 85° C setting.
Note 2: Unit will operate at lower pressures but the maximum rated flow of 32L/min. will not be achieved.
Type of appliance Temperature controlled continuous flow gas ho
t
wate
r
syste
m
Operation With / without remote controls, mounted in kitchen, bathroom etc.
Exhaust system Forced Flue
Rinnai model number
Infinity 32e
Heavy Duty 70e
Installation Externally mounted
Dimensions Width － 470mm
Height － 600mm
Depth － 220mm
Weight 29 kilograms
Maximum / Minimum
Gas consumption
Natural gas：69 - 5.6 kW
Propane gas：69 - 5.6 kW
Connections Gas connection － 3/4 inch BSP
Cold water connection － 3/4 inch BSP
Hot water connection － 3/4 inch BSP
Ignition system Direct electronic ignition
Electrical consumption Normal － 83 W
Standby
－
12 W
（
With 1 Remote control
）
With Anti-frost protection
－
100 W
Hot water capacity（Raised 25℃） 32 to 2.7 L/min
Thermal efficiency 81%
Kitchen controller（MC)
:
37 - 55℃ Temperature range
(with remote)
Bathroom controller (BC) ：37 - 50℃
Default temperature control
(without remote)
40
℃、
43
℃、
50
℃、
55
℃、
60
℃、
65
℃、
75
℃、
85
℃
（
Set by combination of Dip switches on PCB
）
Water flow control Electronic Water flow sensor, flow control & heat exch.
By-pass flow control.
Minimum operating water pressure(Note 2) 1.8 bar
Nominal operating water pressure 2.0 bar - 10.0 bar
Minimum operating water flow 2.7 L/min
Maximum operating water flow 32 L/min
Power supply Appliance － AC 230 Volts 50Hz
Remote control － DC 12 Volts （ Digital ）
Noise Level 49 dB(A)
Flame failure － Flame rod
Boil dry － Water flow sensor
Remaining flame （ OHS ） － 97℃ bi-metal switch
Over temperature － 95℃ lockout thermistor
Fusible link － 129℃ Thermal Fuse
Pressure relief valve － Opens 20.6 bar. Closes 14.7 bar
Combustion fan rpm check － Integrated circuit system
Safety device
Over current － Glass fuse （ 3 Amp.）
Kitchen control
－
MC-91-1A or MC-70-2A
Bathroom control －MC-91-1A or BC-70-2A
Remote control optional
Second bathroom control －MC-91-1A or BC-70-2A
Remote Controller Cable ( optional ) Two core sheathed (double insulated), flex with min. cross-sectional area of 0.5m²
Manifold Electronic Control
System(optional)
MSA-S
