Rinnai INFINITY A24 - Commissioning; Commissioning steps

14 | Rinnai INFINITY EF26 and A-Series installation guide 01-20
Commissioning
AS/NZS 5601.1, clauses 2.6.8 and 6.11.2,
states that every part of a gas installation shall
be commissioned prior to initial use. It is the
installer’s responsibility to ensure all current
AS/NZS 5601 requirements are met. The URL’s
provided are links to short videos on how key
steps are performed.
The appliance operation must be tested
after installation. Ensure the building
occupants do not have access to the
hot water outlets during this procedure.
Please note
The Rinnai INFINITY EF26 and A-Series come
with a factory preset outlet temperature of
55 °C. The high and low gas operating
pressures are also factory preset. Under
normal conditions the operating pressures do
not require adjustment during installation. Make
adjustments ONLY if the unit is not operating
correctly and all other possible causes for
incorrect operation have been eliminated.
Inlet supply pressure to the appliance MUST
BE checked and set within the operating
parameters of the appliance in all instances.
If the appliance can not be adjusted to perform
correctly call 0800 RINNAI (0800 746 624) for
assistance.
WARNING
Commissioning steps
1
Flush water pipes and
gas line
Before nal connection of the water heater , ush the gas, hot and cold water
supply lines. Swarf in the gas or water supplies may cause damage, a common
problem, which is not covered by warranty.
2
Connect the gas line
3
Purge the gas line of air
4
Final connection test
5
Check supply pressure Operate ALL other gas appliances at their maximum rate. With all gas appliances
on maximum the supply pressure must read between 1.13-3.0 kPa on Natural gas
and on LPG 2.75-3.0 kPa.
If the pressure is lower, the gas supply is inadequate and the appliance will not
operated to specication. It is the installer’s responsibility to check the gas meter,
service regulator and pipe work for correct operation and sizing, and rectify as
required.
6
PCB settings checked Refer sideways ue diverter information on the next page and the PCB interface
layout and functions page.
PCB settings checked if the factory default temperature has been changed.
Dip switch settings checked if a sideways ue diverter is tted.
Short video: http://rinnai.co.nz/007
7
Operate and test for
gas leaks
Replace the appliance front cover otherwise the unit won’t operate correctly, and
operate and test for gas leaks using an electronic leak detector.
8
Operational test Conrm the water ow and hot water delivery temperature using a thermometer.
If water controllers are tted, it is necessary to test their operation through the
complete range of functions, refer separate instructions provided with the water
controllers.
