Rinnai Australia - 16 - Solar Split Systems Operating / Installation Manual- Version 9 - 21/11/12
GAS BOOSTER SPECIFICATIONS
* Table 4 - Gas Boosters Specifications
Model Name S20 S26 S26i * S32 *
Boost Capacity:
- L/min. @ 20°C rise
- L/min @ 25°C rise
(L/min)
20
16
26
24
26
24
37
32
Maximum Rated Flow:
(L/min)
20 26 26 37
Minimum Water Supply Pressure for
Maximum rated flow:
(1)
(kPa)
120 200 200 180
Frost Protection: Yes
Gas Consumption (Maximum /
Minimum):
(MJ/
Hr)
125 - 18 188 - 23 188 - 14 250 - 21
Hot Water Delivery Temperature:
(2)
70°C
Dimensions: Height x Width x Depth:
(mm)
530 x 350 x 194 600 x 470 x 244
Weight:
(Kg)
15 21 15 29
(1)
- Units will operate at lower pressures but the rated flow will not be achieved.
(2)
- Gas boosters for Solar hot water applications must be set by Rinnai to deliver a minimum temperature of 70°C. Solar Gas boosters
will be marked as Solar. Units not marked ‘Solar’ MUST NOT be used.
* These models are made to order.
