Rinnai Australia - 39 - Solar Split Systems Operating / Installation Manual - Version 9 - 21/11/12
Glass Lined SG270, ESG270, SG270SL, ESG270SL, SG340, ESG340, SG320SL
or ESG320SL with SGPKIT3
Items Supplied with Cylinder
Items Supplied in SGPKIT3 (cont…)
1
1
PTR Valve 92501192
13
1
Elbow ¾ Rp x ¾ G flexi 21201012
1
Adaptor R ¾ x Rp ½
14
2
Fibre Washer ¾ 17401008
3
3
Adaptor R ¾ x Rp ¾
Items Supplied in SGPKIT3
4
1
R ¾ Nipple 17201005
15
1
Insulated Flexi Pipe
1080 mm
11601069
8
1
Cold Inlet Copper T 11603921
9
1
G3/4 (Comp) x R ¾ union 32201713
16
2
Gas Booster Mounting Brackets
1 x tabs bent
26601098
1 x tabs unbent 26601096
17
1
Adaptor Rp ¾ x G ¾ (flexi) 16601006
14
Screws 22601048
- 1
Operation and
Installation Manual
15401021
11
1
Pump & Controller Assembly 39001735
includes:
x 2 x ½” Kinco nut & olive
x Flow control valve 11001033
x Non return valve 27801713
x Temperature sensor lead 31002710
x Pump 30001703
x Control Box 31002703
- 1 Warranty booklet 15401041
- 1
STC form
15401023
12
1
Temperature Sensor with 2 m lead
Part of Pump and Controller Assembly
(39001735), but shown separately
for clarity in diagrams 31002710
- 1
Gas Booster
Mounting Template
15401034
To Next Page
