Rinnai SPLIT SOLAR - Page 43

Rinnai Australia - 41 - Solar Split Systems Operating / Installation Manual - Version 9 - 21/11/12
Glass Lined SG270, ESG270, SG270SL, ESG270SL, SG340, ESG340, SG320SL
or ESG320SL with SGPKIT3A
Items Supplied with Cylinder
Items Supplied in SGPKIT3A (cont…)
1
1
PTR Valve
92501192
13
1
Elbow ¾ Rp x ¾ G exi
21201012
1
Adaptor R ¾ x Rp ½
14
2
Fibre Washer ¾
17401008
3
3
Adaptor R ¾ x Rp ¾
Items Supplied in SGPKIT3A
4
1
R ¾ Nipple
17201005
15
1
Insulated Flexi Pipe
1080 mm
11601069
8
1
Cold Inlet Copper T
11603921
9
1
G3/4 (Comp) x R ¾ union
32201713
16
2
Gas Booster Mounting Brackets
1 x tabs bent
26601098
1 x tabs unbent 26601096
17
1
Adaptor Rp ¾ x G ¾ (exi)
16601006
-
14
Screws
22601048
- 1
Operation and
Installation Manual
15401021
11
1
Pump & Controller Assembly 39001739
includes:
t 2 x ½” Kinco nut & olive
t Flow control valve 11001033
t Non return valve 27801713
t Temperature sensor lead 31002710
t Pump 30001754
t Control Box 31002703
- 1 Warranty booklet 15401041
- 1
STC form
15401023
12
1
Temperature Sensor with 2 m lead
Part of Pump and Controller Assembly
(39001735), but shown separately
for clarity in diagrams
31002710
- 1
Gas Booster
Mounting Template
15401034
INSTALLATION & MAINTENANCE - GAS BOOSTED SYSTEMS
